by Steven B. Combs, Ph.D.
tags: howto - creality - ender3 - 3dprinting - 3dprinter - setup

In my last post I journaldocumented my experience assembling my new Creality Ender-3 3D printer. As I mentioned in that post, I have no experience with 3D printer and have no idea what to do first. Luckily, a video from 3D Printing Canada was just what the doctor ordered.

3D Printer Assembling: The Creality Ender 3 At the beginning of the year I had several ideas where additive manufacturing would make sense to create a first prototype. Asking around who can help me with a 3D print on demand makes me tired so I began to search a cheap solution for myself. Ultimaker Cura is free, easy-to-use 3D printing software trusted by millions of users. Fine-tune your 3D model with 400+ settings for the best slicing and printing results. 4. 2d animation software mac free download. Software Installation. Preparing to Print. Circuit Wiring Diagram. For Gearbest customers: If you've purchased Creality3D Ender - 3 DIY 3D Printer Kit from us and still have problem after reading the user.

NOTE: This post is part of a series on 3D Printers. More posts to come.

I’ll follow ]that video and prepare my printer. Like my previous post, this post will be in a journal format. Best voice recording software for windows 10.

There is a fair amount of wobble in my 3D printer. The steps to loosen the base brackets worked for me and I only had to loosen and tighten the left bracket.

The video says I should not be able to rotate the idler by hand. I can, so I need to tighten it per the instructions. In my case, this means rotating the nut counter-clockwise. About a quarter turn and the roller is perfect. I can’t move it with my fingers and the gantry moves up and down smoothly.

This seems like a step I will need to do regularly so I need to pay attention to this one. I need a business card or a post-it note. Now where can I find one of those? Alright, have a post-in note and I need to feed a pet; be back in a bit.

Back to the video. Turn the printer on. Got it. Select Prepare / Auto home on the controller. Place the print head at one corner of the build surface on top of the bed level adjustment dial.

• Clockwise to move bed closer to print head
• Count-clockwise to move bed away from print head

I should be able to move paper under the print head but with some slight resistant. Okay, that seems right. https://downjfiles383.weebly.com/chrome-screenshot-full-page-console.html. Just a slight amount of drag as I pull and push paper between the print head and the build surface. Now I repeat for the remaining three adjustment dials.

Next, I adjust the opposite corner. Since this was an out of the box leveling, it took some time to get it right and I had to repeat the process a couple of times. Still not sure its perfect, but I will get better over time.

https://besttup519.weebly.com/the-cracker-factory.html. The first step is to move the head high enough from the build surface so I can purge some of the filament:

Select Prepare / Move Axis / Move Z / 40mm on the controller.

I’m going to use PLA filament, so I will preheat the bed and the nozzle for that material.

Select Prepare / Preheat PLA / Preheat PLA on the controller.

The default temperature for Preheat PLA is 180° and the suggestion is to make it 200°. I’m going to change that setting and store 200° as the default setting.

Select Control / Temperature / Nozzle: / 200° on the controller.

Select Control / Store settings / and wait for beep.

Now that the temperature is set to a new default, I’ll wait for the temperature on the display to reach 200°.

Time to load filament. I purchased a MIKA3D three pack (black, white, and red) (#Ad) from Amazon for around $30 when I used the online 5% off coupon. I’m going to start with red, because I want all my 3D printer upgrades (that I will print using the 3D printer) printed in red and give me a cool black and red theme.

Free Model Download – Creality 3D - Creality3D® Printers

{UPDATE: I changed my mind. I’m printing all upgrades in black to make them appear more like default accessories.}

Place the spool on the holder and be careful to not let the spool unwind on itself (which it almost did). Time to pull slightly enough filament off the roll so I can cut the end of the filament at a 45° angle. I get to use those nifty cutters supplied with 3D printer.

This next part appears tricky and the video is spouting out a bunch of terms like extruder lever, filament hole, extruder wheel, idler bearing, and PTFE tube! Problem is, the video doesn’t show these items up close so I have no idea what the presenter is talking about. I’ll give it a shot anyway. The premise seems to be; just push the filament through the tube until molten material comes out of the print head and on to the build surface.

What the devil? I can’t get the filament into the filament hole. There seems to be blockage. Frustrated, I pulled out an Allen wrench with about the same diameter of the filament and I was able to push that all the way through. It must be that the filament’s sharp point it snagging on a lip created by the connection of two parts.

Also of note, I need to barely push the extruder lever together. Too much and the filament will pushed out and away from the filament hole. Still struggling getting the filament through the hole. There must be some trick to this that I am missing.

Found this Reddit comment that helped. Thanks mickeybob00! Now I am able to push the filament through the tube and toward the print head, but alas, no material is coming through the print head! Oh, woe is me.

After more fiddling with the filament, I finally have extruded material! I just had to jiggle the feeder tube at the print head, push the filament again into the tube, and it started shooting out!

I removed the extruded material from the print head and the build surface. I think I’m ready for my first print!

Didn’t put the microSD card in the printer. Turing printer off, then on, and preheating the PLA again. Now I can try my first print.

UPDATE: The 3D printer includes a refresh TF Card option. I could have used that instead of cycling the printer on and off.

Ultimaker Cura: Powerful, Easy-to-use 3D Printing Software

Per the video:

Best free virus protection for macbook pro. Select Print from TF / Test-dog.gcode

Cool (reverse pun intended), the build surface heats up automatically based on the .gcode. Looks like 50°. Now the printer is homing automatically. And it’s printing! This is a bit larger than I wanted. I may not complete the whole dog as it is burning through my red PLA. Everything seems to be working well though. Lunch time! Mac app blocker 3 2 – password protect apps without.

Several hours later and this “dawg” is still printing!

In the meantime, I need to finish an Ubuntu Linux install on an older i5 computer with 8Gb. I’ll install 3D printing software Cura and FreeCAD. I’ll use the appImage versions.

5 hours and 41 minutes later (which the slicer predicted). Everything I read says to wait until the build surface and print head cool completely before removing the print. I’m going to go out for a three mile run. The printer should be cooled down by the time I complete my own cool down.

Forgot that the build surface comes off the 3D printer. I removed the binder clips and build surface. I should be able to pop the print off by easily bending the build surface. Popped right off! No material left on the cover. Nice.

Only thing left do to is clean off the support material. I’m going to get another print started (a fan cover for the printer) and head out for a run before I do that though.

NOTE: I changed the color of the filament. To do this, I had to turn the printer back on and heat the print head back to 200°. When I pushed the extruder lever and pulled the filament, it came right out. I then pushed enough black filament through to clean out the red.

I showed the 3D print to Nikki and she wanted to help break off the support material. She’s claimed the dog on her desk. Love it! The dog is hers.

The next day and I’ve already found issues. I was trying to print some upgrades and found that the base layer of my prints would not stick. I believe my build surface has already cupped in the middle. I cannot level the bed to get a good layer of filament down. While leveling is perfect underneath the spring levelers, when I move to the middle of the bed, there is too much room between the bed and the print nozzle.

After some research, this seems to be common. Especially if you bend the build surface to remove a print; which I have been doing. WARNING to new users, don’t do that! The fix is to get a new build surface. I’m going to order a Creality glass build surface (#Ad) to replace it. Glass will not warp and is recommended by many online. I’ll let you know how it goes. Until it arrives, I have been able to print smaller objects. I modify the location of the model on the build surface, in Cura, to one of the quadrants of the build surface where there is less warping. That works so far. I am printing a 3D printer upgrade part while I type.

I’ve learned a whole lot more about my printer since my previous post as well as what I should and shouldn’t do in the future. The build surface issue would have happened eventually. It is just a shame that Creality doesn’t just include a glass build surface by default. The fact that I have to purchase another build surface adds an extra $20 to the total cost. Disappointing. As long as that solution works, I feel I can still be happy with my purchase.

I hope this post helps other Creality Ender-3 3D printer owners. Let me know in the comments below if I missed something or made an inaccurate statement.
